S10B-PHDSS | ||
|---|---|---|
Digi-Key Part Number | 455-S10B-PHDSS-ND | |
Manufacturer | ||
Manufacturer Product Number | S10B-PHDSS | |
Description | CONN HEADER R/A 10POS 2MM | |
Manufacturer Standard Lead Time | 16 Weeks | |
Detailed Description | Connector Header Through Hole, Right Angle 10 position 0.079" (2.00mm) | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | S10B-PHDSS Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Bulk | |
Product Status | Active | |
Connector Type | ||
Contact Type | Male Pin | |
Pitch - Mating | ||
Number of Positions | ||
Number of Rows | 2 | |
Row Spacing - Mating | ||
Number of Positions Loaded | All | |
Style | ||
Shrouding | Shrouded - 4 Wall | |
Mounting Type | ||
Termination | Solder | |
Fastening Type | Detent Lock | |
Contact Length - Mating | 0.114" (2.90mm) | |
Contact Length - Post | 0.118" (3.00mm) | |
Overall Contact Length | - | |
Insulation Height | 0.197" (5.00mm) | |
Contact Shape | Square | |
Contact Finish - Mating | Tin | |
Contact Finish Thickness - Mating | - | |
Contact Finish - Post | Tin | |
Contact Material | Copper Alloy | |
Insulation Material | Polyamide (PA), Nylon, Glass Filled | |
Features | - | |
Operating Temperature | -25°C ~ 85°C | |
Ingress Protection | - | |
Material Flammability Rating | UL94 V-0 | |
Insulation Color | Natural | |
Current Rating (Amps) | 3A | |
Voltage Rating | 250V | |
Mated Stacking Heights | - | |
Contact Finish Thickness - Post | - | |
Applications | - | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | |
| Product Training Modules | PHD Connectors |
| HTML Datasheet | PHD Series Datasheet |
| EDA Models | S10B-PHDSS Models |
| Product Drawings | PHD Series Side Entry |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS non-compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| ECCN | EAR99 |
| HTSUS | 8536.69.4040 |
In-Stock: 25,742
Quantity
All prices are in AUD
Bulk
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | $0.85000 | $0.85 |
| 10 | $0.74800 | $7.48 |
| 100 | $0.61590 | $61.59 |
| 500 | $0.53556 | $267.78 |
| 1,000 | $0.44185 | $441.85 |
| 5,000 | $0.38829 | $1,941.45 |
| 10,000 | $0.36151 | $3,615.10 |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 455-1775-ND S10B-PHDSS(LF)(SN) 455-1775 S10BPHDSSLFSNP S10B-PHDSS (LF)(SN)(P) S10B-PHDSS(LF)(SN)(P) 455-S10B-PHDSS |
| Standard Package | 500 |
