B10B-PHDSS is out of stock and can be placed on backorder.
Available Substitutes:
Similar
Similar
_tmb.jpg)
Similar
_tmb.jpg)
Similar
Similar
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
B10B-PHDSS | ||
|---|---|---|
Digi-Key Part Number | 455-B10B-PHDSS-ND | |
Manufacturer | ||
Manufacturer Product Number | B10B-PHDSS | |
Description | CONN HEADER VERT 10POS 2MM | |
Manufacturer Standard Lead Time | 16 Weeks | |
Detailed Description | Connector Header Through Hole 10 position 0.079" (2.00mm) | |
Customer Reference | ||
Datasheet | Datasheet | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Bulk | |
Product Status | Active | |
Connector Type | ||
Contact Type | Male Pin | |
Pitch - Mating | ||
Number of Positions | ||
Number of Rows | 2 | |
Row Spacing - Mating | ||
Number of Positions Loaded | All | |
Style | ||
Shrouding | Shrouded - 4 Wall | |
Mounting Type | ||
Termination | Solder | |
Fastening Type | Detent Lock | |
Contact Length - Mating | 0.114" (2.90mm) | |
Contact Length - Post | 0.118" (3.00mm) | |
Overall Contact Length | 0.291" (7.40mm) | |
Insulation Height | 0.256" (6.50mm) | |
Contact Shape | Square | |
Contact Finish - Mating | Tin | |
Contact Finish Thickness - Mating | - | |
Contact Finish - Post | Tin | |
Contact Material | Copper Alloy | |
Insulation Material | Polyamide (PA), Nylon, Glass Filled | |
Features | - | |
Operating Temperature | -25°C ~ 85°C | |
Ingress Protection | - | |
Material Flammability Rating | UL94 V-0 | |
Insulation Color | Natural | |
Current Rating (Amps) | 3A | |
Voltage Rating | 250V | |
Mated Stacking Heights | 8.8mm | |
Contact Finish Thickness - Post | - | |
Applications | - | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | |
| Product Training Modules | PHD Connectors |
| HTML Datasheet | PHD Series Datasheet |
| Product Drawings | PHD Series Top Entry |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8536.69.4040 |
0 In Stock
Quantity
All prices are in AUD
Bulk
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | $0.78000 | $0.78 |
| 10 | $0.68600 | $6.86 |
| 100 | $0.56490 | $56.49 |
| 500 | $0.49122 | $245.61 |
| 1,000 | $0.40526 | $405.26 |
| 5,000 | $0.35614 | $1,780.70 |
| 10,000 | $0.33158 | $3,315.80 |
Manufacturers Standard Package
(SN)(P)_tmb.jpg "B8B-PHDSS(LF)(SN)")
Substitutes (5)
| Part No. | Manufacturer | Quantity Available | Digi-Key Part No. | Unit Price | Substitute Type |
|---|---|---|---|---|---|
| 1-1470109-0 | TE Connectivity AMP Connectors | 1,938 | 1-1470109-0-ND | $51.00000 | Similar |
| DF11-10DP-2DSA(01) | Hirose Electric Co Ltd | 3,814 | H2853-ND | $201.00000 | Similar |
| DF11-10DP-2DSA(24) | Hirose Electric Co Ltd | 5,745 | H10232-ND | $88.00000 | Similar |
| DF11-10DS-2DSA(05) | Hirose Electric Co Ltd | 5,075 | H10171-ND | $177.00000 | Similar |
| DF11-10DS-2DSA(06) | Hirose Electric Co Ltd | 187 | H10185-ND | $300.00000 | Similar |
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | B10BPHDSSLFSNP 455-1762 B10B-PHDSS(LF)(SN)(P) B10B-PHDSS(LF)(SN) 455-1762-ND 455-B10B-PHDSS |
| Standard Package | 500 |
