ECO-S1CP473DA is Obsolete and no longer manufactured.
Available Substitutes:
Direct
Direct
Similar
Similar
Similar
Parametric Equivalent
Parametric Equivalent
_tmb.jpg)
Parametric Equivalent
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
ECO-S1CP473DA | ||
|---|---|---|
Digi-Key Part Number | P6876-ND | |
Manufacturer | ||
Manufacturer Product Number | ECO-S1CP473DA | |
Description | CAP ALUM 47000UF 20% 16V SNAP | |
Detailed Description | 47000 µF 16 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 19mOhm @ 120Hz 3000 Hrs @ 85°C | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | ECO-S1CP473DA Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Bulk | |
Product Status | Obsolete | |
Capacitance | ||
Tolerance | ±20% | |
Voltage - Rated | 16 V | |
ESR (Equivalent Series Resistance) | 19mOhm @ 120Hz | |
Lifetime @ Temp. | 3000 Hrs @ 85°C | |
Operating Temperature | -40°C ~ 85°C | |
Polarization | Polar | |
Ratings | - | |
Applications | General Purpose | |
Ripple Current @ Low Frequency | 7.47 A @ 120 Hz | |
Ripple Current @ High Frequency | 8.591 A @ 100 kHz | |
Lead Spacing | 0.394" (10.00mm) | |
Size / Dimension | 1.181" Dia (30.00mm) | |
Height - Seated (Max) | 2.047" (52.00mm) | |
Surface Mount Land Size | - | |
Mounting Type | ||
Package / Case | Radial, Can - Snap-In | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | TS-UP Series |
| Product Training Modules | LED Lighting Components |
| PCN Obsolescence/ EOL | ECO-S,EET,ECE-C,ECE-T,ECE-3 Series 16/Jun/2014 |
| PCN Design/Specification | Form, Labeling, Material 07/May/2013 |
| PCN Other | Snap-In Al electrolytic REACH 07/May/2013 |
| HTML Datasheet | TS-UP Series |
| EDA Models | ECO-S1CP473DA Models |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Affected |
| ECCN | EAR99 |
| HTSUS | 8532.22.0040 |
Obsolete
Substitutes (8)
| Part No. | Manufacturer | Quantity Available | Digi-Key Part No. | Unit Price | Substitute Type |
|---|---|---|---|---|---|
| 16USG47000MEFCSN30X45 | Rubycon | 0 | 1189-3872-ND | $16.59000 | Direct |
| SLPX473M016E9P3 | Cornell Dubilier Electronics (CDE) | 0 | SLPX473M016E9P3-ND | $4.10077 | Direct |
| 380LX473M016A042 | Cornell Dubilier Electronics (CDE) | 0 | 338-2266-ND | $6.46738 | Similar |
| B41231A4479M000 | EPCOS - TDK Electronics | 265 | 495-B41231A4479M000-ND | $8.02000 | Similar |
| SLPX473M016H7P3 | Cornell Dubilier Electronics (CDE) | 0 | SLPX473M016H7P3-ND | $4.30479 | Similar |
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | P6876 ECOS1CP473DA |
| Standard Package | 100 |
